45 Degree Leg Press | Plate Loaded machine - Compact Series

45-Degree Inclined Leg Press | Lever Machine - Compact Series

The 45-degree inclined leg press from the Fitness Tech Compact Series is designed to develop lower body strength and volume through a powerful and stable guided movement. Thanks to its inclined guide rail system with plate-loaded resistance, it allows training with heavy loads while maintaining a controlled range of motion that promotes intense activation of the quadriceps, glutes, and hamstrings throughout the exercise.

Its robust frame and wide foot platform enable performing the exercise with complete stability even during advanced strength training. The 45° incline maintains a natural pushing trajectory that improves force transfer and offers a safe, comfortable, and highly effective training experience for both professional gyms and high-performance training centers.

Double Load Support per Side for Maximum Weights

Unlike a conventional leg press with a single sleeve per side, this machine features two plate bars on each side, allowing for much higher total loads without compromising movement stability. The inclined guide system keeps the pushing trajectory constant and predictable throughout both the concentric and eccentric phases, ideal for working with maximum loads under full control. Built on a Q235 steel tube frame measuring 50 × 80 × 2.5 mm with a corrosion-resistant galvanized coating, it withstands intensive training in commercial gyms.

Main Features

• 45° Incline: guided and stable movement that facilitates training with heavy loads.
• Plate-loaded resistance up to 600 kg: plate-loaded system allowing progressive adjustment of training intensity.
• Double load support per side: includes two plate bars on each side to support heavy training loads.
• Wide foot platform: allows different foot positions to vary muscle focus.
• Ergonomic backrest: provides stability and support throughout the exercise range of motion.
• Galvanized Q235 steel frame: 50 × 80 × 2.5 mm tubing with anti-corrosion treatment for maximum stability.
• Stainless steel loading sleeves: compatible with Ø50 mm Olympic plates.

Technical Specifications

• Dimensions: 225 × 138 × 155 cm
• Weight: 186 kg
• Maximum plate load: 600 kg (150 kg per sleeve)
• Maximum user weight: 180 kg
• Frame: Q235 steel with corrosion-resistant galvanized coating
• Main tube: 50 × 80 × 2.5 mm
• Loading sleeves: 4 · stainless steel · Ø50 Olympic
• Plate storage supports: 4 · stainless steel · Ø50 Olympic
• Handles: vulcanized rubber grips
• Upholstery: high-density foam with leather-like finish
• Finish: electrostatic powder coating
• Certifications: CE and EN ISO 20957
